Mechanical Ball Joint

Nanjing Deers Industrial Co., Ltd provides dredge ball joints that are typically available for a pipe range of 350 to 1200mm and a tilting angle of 2 x 15 degrees. Other sizes and larger tilting angles can also be supplied. The dredge ball joints have a welded connection to the dredge pipe or, optionally, a flanged connection.

All dredge ball joints are designed, produced, assembled, tested, painted, packed, and transported under the close supervision of the Nanjing Deers team of engineers and quality control. We use strict ISO and ASTM standards to design, produce, and test our dredge ball joints.

INQUIRY

BASIC INFO

Hydraulic driven Quick Coupling-1

Nanjing Deers Mechanical ball joints for dredgers are optimal designed and special used for dredging and mining industries, our products are based European standard, however, we optimal the material with more appropriate material, the contact ball surface we use special material for coating, the advantage is:

More anti-corrosive and anti-wear
Pinch type connection with heavy duty clamps
Easy lock mechanism
Robust structure designed to operate in harsh environments
Request for little maintenance
More life time and lower downtime
Angle from 15 degree to 20 degree is available
Working pressure from 10 to 30bar is available

For the channel passage, we optimal the shape of the passage and this let us keep the same flow capacity when dredge the material with different angle. Our ball joint is better than European brands.

For the size of this mechanical ball joint, we accept custom-made, size from ID 250 to ID1200.
